High speed and stable machine & Excellent after sales service
Machine size(L*W*H):8600*1500*2500(4m)
Working width:4m
M/C gauge:1/5+1/5(both sides),1/4+1/4(both sides)
Main structure:cast frame and six position foot screw ensure machine stability
Total power ref.:45KW(4m)
Mechanical speed:600 RPM
Pile height:2.5-9mm
Stitch rate:25-60 stitches/10cm
Primary back roller loading:cylinder automatic control
Primary back fabric feeding:double servo motor control
Gauge parts:both Groz and China made available.
Adjustable bed plate:flexible manual control.
Standard power cabinet and operation cabinet with 12.5″touch screen
Industrial computer with latest windows system
Puller roller:servo motor control
Sliding:double needle bar sliding,max.Max.15 needles on left or right
Yarn feeding:servo control 2+2 or 3+3 or 4+4
| Series | MTC-GH (GN) | |||
| Name | SMALLTURF | HEAvYTURF | ||
| Gauge | 5/32,3/16 | 3/8,5/16,5/8 | ||
| Width | 1M-5M | 1M-5M | ||
| Pile Height | 6-20 MM | 20-65 MM | ||
| Stitch | 15-40 st.∕10CM | 10-35st.∕10CM | ||
| Speed | GH (High Speed) 700-900RPM | GN (Normal Speed) 450-550RPM | GH (High Speed) 450-800RPM | GN (Normal Speed) 300-450RPM |
Shipping terms
- 1. 100% T/T in advance.
- 2. 30% T/T in advance, and 70% against copy of Bill of Lading (B/L).
- 3. 100% by Irrevocable Letter of Credit at sight.
- 4. 100% by D/P at sight（The specific payment terms can be confirmed according to the circumstances of both parties.）.
Packing and shipping
- 1. Standard export packing is provided for this machine.
- 2. tufting machine requires 1x40HQ or 2x40HQ containers for loading,special requirements needs to be negotiated specifically.
- 3. Before shipment, we will confirm with the customer the test video of the machine operating properly.
WARRANTY:
- 1. Warrant for Electrical parts: 1 year, customer bear courier/airfreight charge
- 2. Warranty for Control Panel: 1 year
- 3. Mechanical parts (not including consuming parts) 1 year
FAQ
Q 1: Payment terms capacity?
A 1: T/T, L/C, Western Union etc.
Q 2: Trade terms?
A 2: In according with Incoterms 2010, normally with EXW, FOB shanghai, CFR, CIP, CIF and DDU.
Q 3: Validity of quotation?
A 3: Within 45 days.
Q 4: Modes of shipment?
A 4: By sea or railway.
Q 5: Warranty?
A 5: One year. Will offer after sell service in whole life of machine use under compensation after one year.
Q 6: Installation and training?
A 6: We have installation and technical support teams in India, Brazil, and Egypt. For other countries, we can provide paid overseas engineering services.
